Roof plan of 18x17m ground floor of house plan is given in this Autocad drawing file.Download now.


Description

Roof plan of 18x17m ground floor of house plan is given in this Autocad drawing file. This is G+1 house plan. 150mm thickness of concrete slab, 150x450mm parapet wall, 50x75mm pulins, 25x300mm fascia board, roofing sheets, and ridge cap are mentioned. In this ground floor plan porch, water closet, living area, master bedroom with attached bathroom, kitchen, dining area, indry, store room, master bedroom with attached water closet & dressing area, kid’s room with attached toilet, corridor and guest room with attached toilet are available. For more details download the autocad drawing file. Thank you for downloading the Autocad file and other CAD program files from our website.




File Type: DWG File ID: 173827
