Two plans and section of pile cap details.


Description

This Architectural Drawing is AutoCAD 2d drawing of Two plans and section of pile cap details.  The pile cap should overhang the outer piles, typically by a distance of 100-150 mm on all sides, depending on the size of the piles. Pile caps are constructed by excavating an area around the group of piles to enable formwork to be inserted. The pile tops may be trimmed to ensure they are at the same height. For more details and information download the drawing file.
