Architect Apartment CAD Drawing with Floor Plans Sections Elevation

This Architect Apartment CAD Drawing DWG file provides a complete architectural documentation set for residential apartment planning and construction. The drawing includes ground floor and first floor layout plans with clearly defined living rooms, bedrooms, dining areas, kitchens, washrooms, circulation corridors, staircases, and parking spaces. All plans are prepared with accurate grid lines, wall thickness, column placement, slab levels, and room dimensions for precise site execution. The file also contains front elevation drawings showing façade design, balcony projections, window alignment, and exterior finishes. Sectional views illustrate floor heights, staircase details, beam depths, and roof structure for better construction clarity.
