Door frame installation and structure details of school dwg file


Description

Door frame installation and structure details of school that includes a detailed view of door elevation details with wires and fences and galvanized mesh with clamps galv, aluminum couplings amarres galv, rh place 1 into the spot and 2 in the corners, pe as reinforcement in straight sections, technical specifications and model selection, symbology details, dimensions details with joints details and much more of door installation details.




File Type: DWG File ID: 106888

Uploaded by:


Presenting the broken author avatar :D Eiz Luna
New-Zealand
