Support of wrought on brick walls cad construction details dwg file


Description

Support of wrought on brick walls cad construction details that includes a detailed view of layer- wall core polystyrene base material thickness of layer-3 of wall of to the base of concrete of thickness, concrete chain, rebar steel rod details and stirrup for chain frame, Hollow for fastening and assembly pvc base material, round so or post-tensioning, steel plate, see detail pl, reinforcement rod square cms and much more of wall details.
