Club House Layout Drawing with Block Planning Floor Plan Details

This Club House Layout Drawing is prepared in AutoCAD DWG format and presents a comprehensive planning layout with multiple residential blocks and common facilities. The drawing includes typical floor plans from the first to sixth floor, block-wise arrangements labeled as Block A, Block B, and Block C, along with circulation cores and stair locations. Front elevation, section views, and internal block connections are clearly illustrated to explain building massing and vertical alignment. The layout shows systematic unit distribution, corridor widths, and access paths with measurable references. Typical block widths range from 18.0 m to 22.0 m, while internal circulation passages are maintained approximately 1.5 m to 2.0 m for smooth movement.
