Stair Detail DWG with Multi Flight Section Landing and Riser

This Stair Detail DWG file provides a comprehensive AutoCAD drawing set showing a reinforced concrete stair construction with multiple flights and intermediate landings. The drawing includes detailed plan views, sectional elevations, and connection details between stair flights and floor slabs. Clear measurements such as riser height, tread depth, landing width, slab thickness, and floor-to-floor height are accurately indicated. The section details illustrate reinforcement placement within the stair waist slab, landing slab connections, and structural support conditions at each level. Handrail alignment and stair enclosure walls are also shown for coordination with architectural layouts.

This AutoCAD DWG stair detail is suitable for architects, civil engineers, interior designers, and builders involved in residential and commercial building projects. The drawing helps users understand stair geometry, vertical circulation planning, and structural continuity between floors. It supports the preparation of working drawings, construction detailing, and site execution planning. The file can be directly used in AutoCAD and referenced in Revit, 3ds Max, and SketchUp workflows for coordination and presentation. Downloading this stair detail through a Cadbull subscription provides accurate and professionally drafted stair drawings for safe and code-compliant construction.
