Longitudinal section of the operating room Elevation detail

 Longitudinal section of the operating room Elevation detail, column c-4 of 0.45 m of armed diameter with 11 rods of 1 "of diameter and stirrups 3/8 "diameter to each 0.15 m to 1.30 m and subsequently @ 0.20 m. enclosure chain armex (f'c = 150 kg / cm2) 12x30 cm section (see structural drawings), flattened with mortar cem-cal-sand prop. 1: 1: 8 brush finish; and recover final tile flange (see finishing plans)
