Wooden constructive structure details of building dwg file


Description

Wooden constructive structure details of building that includes a detailed view of Reinforced concrete parapet,  Stuffed with  tezontle, average thickness, Stuck with cement-sand mortar prop, Waterproofing based on prefabricated membrane, Wall concrete hollow block smooth finish, based on granitic  acrylic resins, Hollow block wall heavy type of cm, common finish, joined with sand cement mortar with horizontal reinforcement and drowned castles, and much more of construction details.




File Type: DWG File ID: 113494

Uploaded by:


Eiz Luna
New-Zealand
