Inner grocery section and second floor plan details of super market dwg file


Description

Inner grocery section and second floor plan details of super market that includes a detailed view of market plant  food, plant - supplies, plant - meat and seafood, lift - food, elevation - supplies, elevation - meat and seafood, cut a - a'- food, cut a - a'- supplies, cut a - a'meat and seafood, detail 2 (columns), detail 3 (cover), detail 5 (container), plane of axes and trusses, cut b - b'- food, masonry wall, blocks of 0.39x0.19x0.09 and much more of market project.




File Type: DWG File ID: 113550

Uploaded by:


Eiz Luna
New-Zealand
