Modern House Plan Design with Section and Elevation CAD Drawing

This modern residential house plan design with section and elevation CAD drawing is provided in AutoCAD DWG format for professional architectural and construction planning. The drawing includes a detailed ground floor plan, a first floor layout, front and side elevation views, and sectional drawings for structural clarity. It shows well-arranged bedroom spaces, a living area, a kitchen, a dining zone, a staircase, a utility space, and an entrance lobby. The design is prepared with an approximate plot size of 9000 mm by 12000 mm, built up area of around 1800 sq ft to 2200 sq ft, and a standard floor height of 3000 mm. Wall thickness of 230 mm, door and window openings, and circulation widths are clearly marked for accurate site execution. This house plan CAD file also provides construction-level detailing such as column grid layout, beam alignment, slab thickness of 125 mm to 150 mm, and roof profile design. Section drawings illustrate floor level connections, foundation depth, and ceiling height. Elevation design presents a modern wooden finish facade with window positioning and entrance proportions.
