Modern Duplex House Design with Layout Plan Section Elevation CAD

This modern duplex house design with layout plan, section A B C, and elevation CAD drawing is provided in AutoCAD DWG format for residential architectural planning. The drawing set includes complete ground floor and first floor layout plans with furniture arrangement, room dimensions, circulation paths, staircase placement, and utility zoning. The duplex house plan is designed with an approximate plot size of 10000 mm by 15000 mm, built up area of 2000 sq ft to 2600 sq ft, and a standard floor-to-floor height of 3000 mm. Wall thickness of 230 mm, door and window schedules, and setback distances are clearly indicated. Section A, Section B, and Section C drawings illustrate structural levels, slab thickness of 125 mm to 150 mm, plinth height, and roof slope alignment.

This house design CAD file also includes front and side elevation detailing with facade treatment, window proportions, balcony elements, and roof profile planning. Interior layout planning supports master bedroom design, living room configuration, dining space arrangement, kitchen layout, and bathroom zoning. Structural grid alignment, beam layout, and column positioning are incorporated for construction accuracy.
