Restaurant Plan and Section CAD Drawing 15m x 30m Layout Design

This Restaurant Plan and Section CAD Drawing 15m x 30m Layout offers a complete architectural design solution for commercial dining facilities. The drawing includes the ground floor restaurant seating layout, dining table arrangement, kitchen preparation area, service counter, washroom block, staircase core, and parking space on the lower level. It also covers first and second floor room planning, staff areas, circulation corridors, and utility zones. The building footprint is approximately 15m x 30m, with clearly marked room dimensions, wall thickness, door and window placements, and structural grid references. Section drawings illustrate floor height levels, stair configuration, slab thickness, balcony projections, and internal spatial relationships.
