construction details section


Description

construction details section dwg file.  The Underfloor, corridor lining ext. of cement, brick wall bricky cliff., wood carpentry, beam chain, ceramic floor, underfloor, double glass, pluvial drainage channel etc




File Type: DWG File ID: 119011

Uploaded by:


Eiz Luna
New-Zealand
