Typical details of reinforcement of wall in plant and cover dwg file


Description

Typical details of reinforcement of wall in plant and cover that includes a detailed view of Reinforced concrete parapet,  Stuffed with  tezontle, average thickness, Stuck with cement-sand mortar prop, Waterproofing based on prefabricated membrane, Wall concrete hollow block smooth finish, based on granitic  acrylic resins, Hollow block wall heavy type of cm, common finish, joined with sand cement mortar with horizontal reinforcement and drowned castles and much more of reinforcement details.




File Type: DWG File ID: 119575
