Precast concrete floor unit bearing an reinforced concrete beam dwg file

Precast concrete floor unit bearing an reinforced concrete beam that includes a detailed view of rainforced concrete beam cast in site, precast concrete floor unit, rainforcing loops cast in top of main beam are wired to tie bars, rainforcing the bars fit in slots cut in ends of floor units and much more of constructive details.
