Warehouse Project DWG with Industrial Layout and Section Details

This Warehouse Project DWG file presents a complete industrial building layout developed in AutoCAD for storage and logistics facilities. The drawing includes a detailed warehouse floor plan showing loading and unloading zones, storage bays, internal circulation paths, and service areas. The typical warehouse layout measures approximately 30000 mm x 20000 mm, providing ample space for material movement and storage operations. Structural planning details such as column grid spacing around 6000 mm, clear internal height of nearly 8000 mm, and slab thickness of approximately 200 mm are clearly indicated. The design supports efficient forklift movement, racking systems, and vehicle access planning.
