Bathroom Plan with Four Side Sections DWG and Fixture Details

This Bathroom Plan and Four Side Section DWG file provides a complete AutoCAD drawing set that includes a detailed bathroom layout along with four-sided sectional views for accurate construction reference. The plan illustrates the precise placement of sanitary fixtures such as a wash basin, water closet, shower area, and bathtub with proper clearances. Typical bathroom dimensions are shown at approximately 2400 mm x 1800 mm, with shower area clearance around 900 mm x 900 mm, wash basin height near 800 mm, and WC seat height approximately 450 mm. Floor finish levels, wall thickness of about 115 mm, and door opening sizes are clearly marked to ensure correct execution on site.
