Retail Shop Plan And Section CAD DWG With Counter Display Sizes

This Retail Shop Plan And Section CAD DWG file presents a clear shop layout with detailed plan and sectional drawings suitable for small to medium commercial spaces. The drawing includes shop floor planning with display counters, storage area, entry shutter line, and customer circulation space. Typical measurements are shown, such as an overall shop size of approximately 4500 x 3600 mm, display counter depth of 600 mm, counter height of 900 mm, and minimum customer movement clearance of 1200 mm. The sectional drawing explains floor to ceiling height of around 3000 mm, counter buildup, and shutter positioning, all drafted to scale with clean linework.
