Commercial Fishing Boat 3D CAD Layout DWG with 24m x 6.8m Size

This commercial fishing boat 3D CAD layout DWG file delivers a detailed and professional marine design with complete structural and deck arrangements. The drawing represents a modern trawler-style vessel with an approximate overall length of 24 meters and a beam width of 6.8 meters. It includes a reinforced hull formation, raised wheelhouse navigation cabin, working deck area, cargo handling zone, and heavy-duty crane mast system. The layout also displays safety railings, equipment platforms, storage compartments, winch supports, and antenna structures. This boat CAD drawing is compatible with AutoCAD 3d Max, Revit, and Google SketchUp and supports efficient planning for fishing vessel construction and offshore operations.
