Door Block Details Solid Wood Swing Paneled Doors with Transom

This AutoCAD DWG door block details drawing provides a complete set of architectural door elevations and sections used for residential and commercial projects. The drawing includes solid wood swing paneled doors with a wood frame and a transom above, prepared for design approval by the architect. Multiple door types are shown with clear labeling, such as single-leaf doors, double-leaf doors, sliding doors, and grilled door variations. Each door block is drafted with accurate proportions, frame thickness, shutter layout, and hardware placement to support consistent detailing across architectural drawings.

The door block details DWG file also includes window blocks and soffit details coordinated with door elevations for uniform design language. Dimension lines, level references, and section markers help in understanding installation requirements and opening sizes. These door blocks are suitable for direct use in floor plans, elevations, and interior detailing drawings. The AutoCAD file is useful for architects, civil engineers, interior designers, builders, and CAD professionals working with AutoCAD, Revit, 3D Max, and SketchUp for building design, documentation, and construction detailing.
