Cafeteria toilets sections and sanitary installation details dwg file


Description

Cafeteria toilets sections and sanitary installation details that includes a detailed view of male toilet sectional details, female toilet sectional details, passage, sanitary equipment installation details, doors and ventilation details, plumbing details, interior details, dimensions details, wall section details and much more of sanitary installation details.




File Type: DWG File ID: 126223

Uploaded by:


Eiz Luna
New-Zealand
