Farm House Layout Drawing with Site Plan Elevation and Room Details

This farmhouse layout drawing provides a complete residential and site planning solution with a detailed layout plan, elevation views, furniture arrangement, and block design. The drawing includes bedroom, living room, dining area, kitchen, utility spaces, and circulation zones with proper zoning and functional connectivity. The site plan is designed within an approximate plot size of 60 ft x 100 ft, featuring landscaped areas, internal pathways, and parking space for three cars measuring around 9.0 m x 5.5 m. External walls of 230 mm and internal partitions of 115 mm are maintained for durability and structural balance. Floor height of approximately 3200 mm ensures proper ventilation and natural lighting. All dimensions and layouts are prepared in AutoCAD format for professional drafting and modification.
