Section details of pluvial drainage in roof constructive details dwg file

Section details of pluvial drainage in roof constructive details dthat includes a detailed view of slope formation layer, elastic expansion joint, aluminum joinery stud, angular anchor, aluminum joinery crosspiece, anchoring to allow movement by dilation, anchor screw, veneer, elastic gasket for glass, elastic sealing gasket, double sheet glass, Water-resistant concrete treatment, false ceiling of plaster plates, false ceiling fastening, profile, ceramic tile, cement-glue adhesive and much more of building construction.
