Circular platform constructive sectional details dwg file


Description

Circular platform constructive sectional details that includes a detailed view of memory of materials, footings details, column view, beam construction, covers closure type 1 and 2, soil  burried wall closure type 1 and 2, exterior solera, holes, interior partition, granite veneer of the country with steel supports, halfeneisen type, Brick partition, 8cm, plaster plastering 1cm, Concrete wall 15cm and much more of platform details.




File Type: DWG File ID: 131816
