Detail unevenness with column and beam construction of building dwg file


Description

Detail unevenness with column and beam construction of building that includes a detailed view of beam construction, covers closure type 1 and 2, soil  burried wall closure type 1 and 2, exterior solera, holes, interior partition, granite veneer of the country with steel supports, halfeneisen type, Brick partition, 8cm, plaster plastering 1cm, Concrete wall 15cm and much more of construction details.





File Type: DWG File ID: 132159

Uploaded by:


Eiz Luna
New-Zealand
