Office building multi flooring front sectional details dwg file


Description

Office building multi flooring front sectional details that includes a detailed view of flooring view, wall design, wall construction, balcony view, doors and windows view, memory of materials, footings details, staircase construction and sectional details, steps details, dimensions, column view, beam construction, covers closure type 1 and 2, soil  burried wall closure type 1 and 2, exterior solera, holes, interior partition, granite veneer of the country with steel supports and much more of building section.





File Type: DWG File ID: 132186

Uploaded by:


Eiz Luna
New-Zealand
