Building constructive section details dwg file


Building constructive section details that includes a detailed view of average thickness, Stuck with cement-sand mortar prop. 1: 5, Waterproofing based on prefabricated membrane, Wall concrete hollow block 15x20x40 smooth finish, based on granyltec acrylic resins, Hollow block wall heavy type of 15x20x40 cm, common finish, joined with sand cement mortar 1: 5, ith horizontal reinforcement and drowned castles, Galvametmonomuro panel 2.5 "and 4" thick, finished with white pre-lacquered galvanized steel sheet, and much more of constructive details.

File Type: DWG File ID: 132240

Uploaded by:

Eiz Luna
