Three-flooring house building facade sectional details dwg file


Description

Three-flooring house building facade sectional details that includes a detailed view of flooring view, wall design, stairacse sectional view, people blocks, construction, balcony view, doors and windows view, memory of materials, footings details, staircase construction and sectional details, steps details, dimensions, column view, beam construction, covers closure type 1 and 2, soil  burried wall closure type 1 and 2, exterior solera, holes, interior partition, granite veneer of the country with steel supports and much more of house building section.




File Type: DWG File ID: 132290

Uploaded by:


Eiz Luna
New-Zealand
