Roof construction details with reinforcement and column dwg file


Description

Roof construction details with reinforcement and column that includes a detailed view of Smooth embossed and riveted zinc-alum roof, vapor barrier. dynafoil asphalt felt,  structural osb board, expanded polystyrene, Extruded plywood, Piece pine wood, brushed dry, Vapor, concrete base and much more of roof details.




File Type: DWG File ID: 132645

Uploaded by:


Eiz Luna
New-Zealand
