Roof Structure Detail with Insulation and Aluminum Window DWG

This roof structure detail DWG file provides an in-depth view of the various components used in roof construction. It includes details such as gravel tiles, mineral wool insulation, PVC channels, dry pine, chains, and aluminum windows with sliding mechanisms. The detailed section views highlight the layering of materials, from the foundation to the roof surface. It offers insight into the structural connections, including the integration of aluminum windows and their placement within the roof assembly. Additionally, the use of mineral wool insulation ensures energy efficiency, and the gravel tiles provide durability and weather protection.
