Curtain walls constructive structure details dwg file
Tags
#wall construction#wall construction dwg file#wall construction design#wall construction plan#wall construction layout#wall construction structure#wall construction project
Ratings & Reviews
⭐
No Reviews Yet
Be the first to share your experience with this product. Your review helps others make better decisions!
★★★★★
Description
Curtain walls constructive structure details that includes a detailed view of counterframe made of wood, fixed frame made of extruded profiles in aluminum alloy, mobile helix consisting of extruded profiles in aluminum alloy, double glazing, central stop, internal platform in folded insulated aluminum, guide for roller shutter in aluminum, insulated folded aluminum shoulders, external aluminum sill and much more of curatin wall details.
Uploaded by:
Eiz Luna
