Wash Basin and WC Ware Block with Plan Elevation Section Sizes

Wash basin, and WC ware block drawing includes detailed sanitary ware layouts of multiple hand wash basins and water closet models prepared in AutoCAD format. The file presents plan, elevation, and section views of different WC types such as Tm 402, Tm 415, Tm 432, Tm 054, and Tm 688 with standard width range from 0.360 m to 0.400 m and installation height around 0.750 m to 0.800 m. Wash basin models such as L 672, L 296, L 147, L 682, and L 319 are shown with basin widths from 0.400 m to 0.600 m and pedestal height near 0.800 m. Each block includes a centerline reference, outlet pipe position of 0.100 m diameter, and fixing alignment for accurate bathroom layout drafting.
