Drainage chamber detail elevation and section 2d view layout autocad file
Ratings & Reviews
⭐
No Reviews Yet
Be the first to share your experience with this product. Your review helps others make better decisions!
★★★★★
Description
Drainage chamber detail elevation and section 2d view layout autocad file, dimensions detail, cross-section detail, concrete masonry required in construction, section line detail, pipe and drainage provided for the outlet of waste, the dimension is given, nut bolt detailing, hatching detail, pipe radius detailing, hatching detail, section detail, etc.
File Type:
DWG
File Size:
41 KB
Category::
Dwg Cad Blocks
Sub Category::
Sanitary CAD Blocks And Model
type:
Gold
Tags
#Drainage chamber
