Contemporary Bathroom Sanitary Ware Layout Plan and Section Detail

This Contemporary Bathroom Sanitary Ware Layout Plan and Section Detail drawing presents a complete bathroom arrangement including wash basin, water closet, bathtub, mirror unit, vanity counter, and door placement with accurate dimension references. The layout shows plan view with fixture positioning, circulation space, and wall thickness, along with detailed sectional views marked as Corte A, Corte B, Corte C, and Corte D. Each section clearly illustrates floor finish levels, wall tile cladding, ceiling height, plumbing lines, and installation depth for sanitary ware units. All sanitary fittings are represented with measured offsets, fixture heights, and structural alignment suitable for residential and commercial bathroom design.

The Contemporary Bathroom Sanitary Ware Layout Plan and Section Detail also includes elevation views showing vanity mounting height, mirror placement, basin counter alignment, WC installation level, and bathtub recess detailing. Dimension annotations indicate floor-to-ceiling height, fixture center lines, tile band positioning, and door width clearance.
