Isometric Outlet Detail with Variable Height Column Board layout

Isometric Outlet Detail with Variable Height Column Board presents a detailed electrical installation drawing showing surface mount board fixed to a metal column with dimension references. The layout illustrates variable height column configuration, rigid metallic conduit routing, and surface-mounted electrical panel alignment. A reinforced concrete base supports the anchored metal column as per the installation design. The drawing clearly identifies outlet mounting position, conduit clamps, junction box placement, and connection pathways along the column surface. Dimensional markings indicate 1.50 meter reference height and adjustable column height for field installation flexibility.
