Club House Detail Drawing with Dimensions for Recreation and Facility

This clubhouse detail drawing presents a comprehensive planning layout prepared in AutoCAD DWG format for recreational and community facilities. The drawing includes a detailed site and building layout showing children's play area, food and dining zones, garden landscaping, gym space, and internal circulation with accurate dimensions. Outdoor elements such as walking paths, water features, green zones, and seating areas are clearly illustrated to support balanced recreational planning. The internal layout defines activity rooms, service areas, and access points to ensure smooth user movement and functional zoning. The drawing also explains spatial coordination between indoor facilities and outdoor landscape areas with clear width, length, and area measurements.
