Modern Window Frame Design Elevation 1500x1800mm CAD Drawing
Tags
#Window CAD drawing#Window elevation plan#Modern window design CAD#Residential window elevation drawing#Modern Window Design Elevation 1500x1800mm CAD file#Detailed window frame elevation AutoCAD drawing 1500x1800mm
Ratings & Reviews
⭐
No Reviews Yet
Be the first to share your experience with this product. Your review helps others make better decisions!
★★★★★
Description
This Modern Window Design Elevation 1500x1800mm CAD Drawing is a professionally detailed AutoCAD DWG file presenting a front elevation layout of a residential window system with precise dimensional specifications. The drawing includes a total window size of 1500mm width and 1800mm height, clearly defining frame thickness, panel divisions, shutter alignment, and handle placement. The elevation illustrates symmetrical side panels with a central operable shutter, maintaining proportional spacing and structural balance.
Uploaded by:
Jafania Waxy
