Footing Design 1200mm RCC Base Section Elevation Plan Detail

Footing Design 1200mm RCC Base Section Elevation Plan is a detailed Foundation CAD drawing prepared for structural construction documentation. This AutoCAD footing design includes sectional elevation at Detail A and Detail B with a reinforced cement concrete base of 1200mm width and 900mm depth. The drawing shows 12mm and 16mm diameter reinforcement bars, 2 inch by 2-inch MS solid member, a base plate of 8mm thickness, and bearing connections clearly dimensioned. The sectional elevation illustrates column embedment, RCC footing block, and plate anchorage with accurate measurement references for site execution.

The plan top view detail defines the square footing layout with uniform edge offsets and centered column alignment for load transfer. This Footing Design drawing supports architects, civil engineers, and builders in preparing foundation section design and plan documentation. The dimensioned sectional views ensure proper coordination of reinforcement placement, base plate fixing, and structural depth levels.
