200x200cm Column Footing Plan with 8Ø14 7Ø16 Reinforcements.

This Column Footing Plan drawing presents a 200x200cm isolated footing and 180x180cm footing layout with detailed reinforcement including 8Ø14 per meter and 7Ø16 per meter bottom bars. The section A A shows column size 40x40cm with 8Ø16 vertical bars and 2Ø8 at 15cm ties. Footing thickness, PCC base layer and clear cover dimensions are clearly marked. Additional reinforcement such as 1Ø12 at 20cm and 8Ø20 top bars are illustrated in plan and sectional views. The Structural Footing Design includes pedestal detailing, bar spacing and concrete levels for accurate construction reference.
