Autocad drawing of the plan, section and elevation details of the car parking shed details given. The drawing has plan and section of three different car parking sheds with same type but different dimensions. First shed has one car parking capacity second shed has two car parking capacity third shed is physically challenged shed. The dimension of the shed are clearly mentioned in the plan. The section drawing gives the detail of GMC column with epoxy paint is used as the column , concrete pedestal as foundation, column is connected with base plate with stiffener and fixed by anchor bolts. Wheel car stoppers are provided in the parking shed.2D elevation drawing are provided for the shed. Cantilever roof with PVDF fabric material is used for the roof of the shred. Thanks for Downloading AutoCAD DWG and other CAD program files from our website.
