General notes and details of a steel pergola has given in the autocad 2D drawing model. Download the Autocad DWG drawing file.

General notes and details of a steel pergola has given in the autocad 2D drawing model. A pergola is a garden feature forming a shaded walkway, passageway, or sitting area of vertical posts or pillars that usually support cross-beams and a sturdy open lattice, often upon which woody vines are trained. Pergolas also give climbing plants a structure on which to grow. Strip footing details were given in this file. RC and PC footing were provided. Thank you for downloading the Autocad files from our cadbull website.
