Staircase Details 3m Floor Height RCC Section and Plan Layout

This Staircase Details drawing provides a comprehensive 3m floor height RCC staircase plan prepared in AutoCAD format with complete dimensional accuracy. The layout includes tread depth, riser height, landing width, waist slab thickness, and structural support detailing. Plan views clearly indicate step alignment, directional movement, handrail positioning, and landing transitions. Reinforcement references, concrete thickness specifications, and sectional annotations are included to ensure structural stability and construction clarity. The drawing also illustrates straight flight and intermediate landing configurations suitable for residential, commercial, and institutional buildings.
