Detail on the elevation of the guide wheel on the floor and rails on the walls are given in the autocad file. Download now.

Detail on the elevation of the guide wheel on the floor and rails on the walls are given in the autocad file. Wheel details are given in this drawing. 21/2 "x2 1/2" x 3/16 "(4.16mm) ptr as main mount structure, 5" rubber wheel, concrete garnish with F`c` = 200 kg / cm² and other details are given in this drawing. For more details download the autocad drawing file. Thank you for downloading the autocad drawing file and other cad program files.
