Detail of Wall Floor Roof Building Section
Description
Detail of Wall Floor Roof Building Section , pre stressed concrete girder and assembly (tightening), Hollow ceramic bricks, Cement and sand bead, Supporting wall of common bricks, Hydraulic insulation, Poor concrete housing, Virapita drainers 0.03m x 0.02m etc detail.
File Type:
DWG
File Size:
31 KB
Category::
Structure
Sub Category::
Section Plan CAD Blocks & DWG Drawing Models
type:
Gold
Uploaded by:
Priyanka
Patel
