Steel Column Base Plate Detail With Bolt Connection Pipe And Plate

This steel column base plate detail drawing presents a structural fabrication layout showing the arrangement of steel plate members, pipe supports, and bolt connections used in the assembly. The drawing illustrates a base plate measuring 2500 x 300 x 2.3t connected with structural components through bolted joints and supporting elements. A steel pipe section sized 20 x 20 x 2t is used within the frame to provide additional support between structural members. Bolt connections, including M10 x 40L bolts and M10 x 80L bolts with washer fittings, are clearly indicated in the detail section. The drawing also shows plate components sized 2500 x 245 x 3t used as part of the structural assembly, along with alignment details and fixing points for installation.
