A section view of the roof truss is given in this Autocad model for 22x32m basketball court plan.Download the Autocad model.
Description
A section view of the roof truss is given in this Autocad model for 22x32m basketball court plan. The distance between each purlin is 1.59m. Depth of the roof truss is 0.53m. For more details download the AutoCAD drawing file. Thank you for downloading the AutoCAD drawing file and other CAD program files from our website.
