Section View of 150x200mm Base Plate with Column CAD Drawing
Ratings & Reviews
⭐
No Reviews Yet
Be the first to share your experience with this product. Your review helps others make better decisions!
★★★★★
Description
A section view of 150x200mm base plate with column is given in this AutoCAD drawing model. The dimension of I section is 400x200x20mm. This plan and section view is given with 1:50 scale. For more details download the AutoCAD drawing file. Thank you for downloading the AutoCAD drawing file and other CAD program files from our website.
File Type:
DWG
File Size:
74 KB
Category::
Structure
Sub Category::
Section Plan CAD Blocks & DWG Drawing Models
type:
Free
Tags
#A section view of 150x200mm base plate with column#Base plate plan and section view#AutoCAD drawing file#2D AutoCAD drawing model#2D AutoCAD model#DWG drawing
Uploaded by:
Pavithra
