Reinforced Concrete Beam Detail With 2 1 2 Inch Steel Angle Support

This reinforced concrete beam detail drawing illustrates the structural connection between a reinforced concrete beam and floor slab with integrated steel angle reinforcement. The section shows steel angles measuring 2 1 2 inch by 3 16 inch positioned at the finished floor level to support the beam edge and structural joint. The drawing includes a reinforced concrete cover and beam body that transfers load into the structural wall and foundation below. A concrete cap layer is placed above the beam edge, providing structural protection and alignment with the finished floor surface. The finished floor layer is clearly indicated along the top level, while a cement mortar and sand mixture with a proportion of 1 to 5 is used as the bedding layer for proper leveling and bonding between structural components.
