Steel Wire Rope Structure Detail With UPN 120mm Support Section

This steel wire rope structure detail drawing illustrates the construction layout of a tension cable system connected with structural steel support components. The drawing includes pipe section details where steel wire rope assemblies are anchored to a structural frame built using a UPN steel profile with a size of approximately 120 mm. The system includes a marine covered steel plate with a thickness of 20 mm that acts as a protective and structural connection plate between the cable assembly and the supporting steel frame. The detail also shows cable fastening components that secure the steel wire rope within the support structure to maintain tension stability. The drawing provides a clear representation of how the wire rope is connected to the structural support plate and steel profile frame, allowing load transfer from the cable system to the structural steel support.
